| Application | Compact 2-way | |
| Nominal Impendance: | Ohm | 8 |
| Power handling AES noise: | W | 400 |
| Sensitivity (1 W / 1 m): | dB | 96 |
| Frequency response: | Hz | 60 – 3000 |
| Voice Coil Diameter: | mm | 62 (2.5″) |
| Voice Coil Material: | Cu | |
| Voice Coil Winding Depth: | mm | 19 |
| Magnet Gap Depth: | mm | 8 |
| Basket: | Cast Aluminum | |
| Effect. diaphragm diameter D | mm | 212 |
Recommended reflex enclosure:
20L/60Hz BRD=80mm/150mm long
| Resonance Frequency: | Fs | Hz | 60 |
| DC Resistance: | Re | Ohm | 5.8 |
| Mechanical Q Factor: | Qms | 5.5 | |
| Electrical Q Factor: | Qes | 0.35 | |
| Total Quality Factor: | Qts | 0.33 | |
| Equivalent Volume: | Vas | L | 30 |
| Moving Mass: | Mms | kg | 0.042 |
| Mechanical Complience: | Cms | mm / N | 0.17 |
| BL Factor: | BL | Tesla m | 16.2 |
| Effective Piston Area: | Sd | m² | 0.0353 |
| Max. linear Excursion: | Xmax | mm | +/- 5.5 |
| Voice Coil Inductance: | Le1k | mH | 0.67 |
| Le10k | mH | 0.42 |
| Overall Diameter: | mm | 388 |
| Mounting Holes Diameter: | mm | 8 x (7 x 8) |
| Bolt Circle Diameter: | mm | 371 |
| Baffle cut-out Diameter: | mm | 358 |
| Overall depth: | mm | 178 |
| Net Weight: | kg | 9 |
Frequency response measured 100W (28.3V) at 1 m on a standard baffle in an anechoic chamber incl. 2nd and 3rd harmonic distortion raised 10 db.
